Technical features

Protection

SEALING: IP66.
IMPACT: IK08.
ELECTRICAL: Short circuit and overvoltage.
Colour temperature and colour rendering index

REINFORCEMENT CIRCUIT: CCT 4000K & CRI >70.
PERMANENT CIRCUIT: CCT 5000K & CRI>70.
Voltage range

DRIVER POWER SUPPLY: AC200~240V
LED MODULE POWER SUPPLY: DC78~90V
Temperature range

-40°C & +40°C
Materials and surface treatments:

LED MODULE CASE:

-Extruded profile of EN AW 6063 aluminium with T5 heat treatment, anodized and blasted.
-Injected polyamide caps.
-Transparent extruded polycarbonate cover.
-Injected polycarbonate lens.

PRINTED CIRCUIT:

-MCPCB (Aluminium 2 mm).

SCREWS AND GLAND SEALS:

-Stainless steel AISI-304.

DC WIRING

-Crosslinked polyethylene, fire resistant and halogen free.
-Copper 1 mm2.
Driver

SEALING: IP67
REGULATION: DALI 2.0.
PFC: >0.95.
HARMONIC DISTORTION: <20% (with charge levels >60%).
MTBF: 308.5Khrs min. MIL-HDBK-217F (25°C)
Efficiency

LUMINAIRE: 150 Lm/W

-LED (100mA & 85°C): 180 Lm/W
-DRIVER (charge 100%): 91%
-LENS (transmittance): 92%
-COVER (transmittance): 97%
Useful life

LED MODULE: 100,000H
DRIVER: 100,000H
DALI

IEC62386-101,102,207
Warranty

LED MODULE: 5 years
DRIVER: 5 years
